Rigging work
11.10 Rigging work on the main boom
Operating Instructions GMK5250L 3 302 633 en 11 - 127
27.09.2017
Depending on the additional equipment, the
truck crane can be equipped with a switchable
air traffic control light.
This air traffic control light (1) has
flashing light
and
constant light lighting modes.
• Select the desired lighting mode using the
switch (2).
Switching on/off
Removing You must remove the rod with the anemometer/air traffic control light
before driving on the road.
• Switch off the air traffic control light.
• Remove the plug and close the sockets (4)
and (5) with the protective caps.
• Wind the cable on to the holder (2).
• Remove the rod (1) from the holder (3).
s
To switch on: Select symbol (1) and confirm – symbol ON is displayed
To switch off: Select symbol (2) and confirm – symbol OFF is displayed
