4.6.3.2.4 Connecting digital load cells from type Pendeo®
The device can be ported to Pendeo® type digital load cells via the xBPI port and the
RS-485 interface (2-wire).
Connections
Color code Color Terminal designation Description
rd red + + Supply voltage
bu blue - - Supply voltage
gr green B B Signal
gy gray A A Signal
The following example shows the connection to the PR 6024/68S junction box using 8
digital load cells, type Pendeo®.
X3 Process Indicator PR 5410 4 Device installation
EN-68 Minebea Intec
