4.6.5.3 Connecting parts for the Connexx module
To connect the Connexx module, the following connecting parts are required:
No. Description Order no.
1 PR 5510/05 CANopen interface for PR 5410 9405 355 10051
2 PR 6154/03 Connexx connecting kit for three load cells (comprising: 2×
PR 6155/05, 1× PR 6152/25, 1× PR 6153/99)
9405 361 54031
3 PR 6154/04 Connexx connecting kit for four load cells (comprising: 3×
PR 6155/05, 1× PR 6152/25, 1× PR 6153/99)
9405 361 54041
4 PR 6154/06 Connexx connecting kit for six load cells (comprising: 5× PR
6155/10, 1× PR 6152/25, 1× PR 6153/99)
9405 361 54061
5 PR 6154/08 Connexx connecting kit for eight load cells (comprising: 7×
PR 6155/10, 1× PR 6152/25, 1× PR 6153/99)
9405 361 54081
6 PR 6155/05 Connecting cable between individual Connexx modules
(M12 plug connector, male → M12 plug connector, female); 5 m
9405 361 55051
7 PR 6155/10 Connecting cable between individual Connexx modules
(M12 plug connector, male → M12 plug connector, female); 10 m
9405 361 55101
8 PR 6152/10 Connecting cable between Connexx module and CANopen
interface (M12 plug connector, female → D-Sub 9-pin plug connector,
female); 10 m
9405 361 52101
9 PR 6152/11 Connecting cable between Connexx module and CANopen
interface (M12 female → open cable ends incl. D-Sub 9-pin plug connec-
tor, female with screw connectors); 10 m
9405 361 52111
10 PR 6152/25 Connecting cable between Connexx module and CANopen
interface (M12 plug connector, female → D-Sub 9-pin plug connector,
female); 25 m
9405 361 52251
11 PR 6152/26 Connecting cable between Connexx module and CANopen
interface (M12 plug connector, female → open cable ends incl. D-Sub
9-pin plug connector, female with screw connectors); 25 m
9405 361 52261
12 PR 6152/40 Connecting cable between Connexx module and CANopen
interface (M12 plug connector, female → D-Sub 9-pin plug connector,
female); 40 m
9405 361 52401
13 PR 6152/41 Connecting cable between Connexx module and CANopen
interface (M12 plug connector, female → open cable ends incl. D-Sub
9-pin plug connector, female with screw connectors); 40 m
9405 361 52411
14 PR 6153/98 Split cable gland for connecting cable PR 6152/.. with D-Sub
plug connector, female
9405 361 53981
15 PR 6153/ 99 Terminating resistor for Connexx module (M12 plug
connector, male)
9405 361 53991
X3 Process Indicator PR 5410 4 Device installation
EN-76 Minebea Intec
