System Configuration (TX-Z 308)
Name Description
Quantity
/System
Remarks
NX.E-308M TXZ ME TX-Z 308 Main Equipment 1
CPU, Power Supply,
battery charger, 3-Trunk/8-
extension interface, ringer,
1 PF transfer circuit
included.
NX.E-6TD TXZ KTS 6 Line keys, standard type Key
Telephone
NX.E-6TXD TXZ KTS 6 Line keys, display type Key Telephone
NX.E-12TD TXZ KTS 12 Line keys, standard type Key
Telephone
NX.E-12TXD TXZ KTS 12 Line keys, display type Key Telephone
1st Model.
Modular station cable
included.
NX.E-6BTD TXZ KTS 6 Line keys, standard type Key
Telephone
NX.E-6BTXD TXZ KTS 6 Line keys, display type Key Telephone
NX.E-12BTD TXZ KTS 12 Line keys, standard type Key
Telephone
NX.E-12BTXD TXZ KTS 12 Line keys, display type Key Telephone
1 to 7
2nd Model.
Modular station cable
included.
NX7E-3SMDR-A1 SMDR interface card 1
Note 2
NX7E-3DHEXU-A1
Doorphone I/F, relay contacts, EXMOH
input, EXP output
1
Note 2
Music source is required
for EXMOH.
NX7E-3FAXU-A1 FAX Transfer /DUD Interface Card 1
Note 2
NX7E-3CIDU-A1 Caller-ID Interface Card 1
Note 2
Complied with Bellcore
Spec.
NT-S-D6 2-wire doorphone box 2
DX2E-32i/NX7E
BATTERY BOX
External backup battery box 1
NP2.6 or equivalent
batteries are required.
NX.E TXZ W.M.K Wall-mount bracket As
needed
NX.E TXZ
ABB.CARD SET
Pull-out type abbreviated dial number
card (20 pcs)
As
needed
DX.E
ABB.CARD SET
Stand type abbreviated dial number card
(20 pcs)
As
needed
1 pce. per key telephone.
Note 1:
The above list shows composition of a system with full capacity.
Note 2:
A maximum of
2
out of these 4 optional cards can be installed in TX-Z 308 Main
Equipment.
<Abbreviations used>
EXMOH: External Music On Hold
EXP: External Paging
KTS: Key Telephone Set
ME: Main Equipment
SMDR: Station Message Detail Recording
SLT: Single Line Telephone
DUD: Direct Universal Dialing
