List of SMDR Printout Data
¾ 4-111 ¾
1. Printout Data
Printout start position
Type of Data
Title Data
Data
digits
Contents of Data
CLS 1 1 3 OTG .......Outgoing call
INC.........Incoming call answer/No answer
OTR .......Transfer of outgoing call line
ITR .........Transfer of incoming call line
BRD .......Toll Restriction
ATB........Busy (Queuing group)
BFL ........Buffer over
DATE 8 6 8 DD/MM/YY......Day/Month/Year
TIME 18 16 8 HH:MM:SS......Hours:Minutes:Seconds
LINE 25 26 2 Line number (OTG, INC, OTR, ITR, BRD)
Buffer over (BFL)
Queuing group number (ATB)
DURATION 30 30 8 HH:MM:SS......Hour:Minutes:Seconds
Conversation time (OTG, INC, OTR, ITR)
Busy time (ATB)
ST# 40 40 2 Extension number
DIALED# 49 45 24 Dialed telephone number (Max. 24 digits)
(OTG)
Caller’s Telephone number and/or Caller’s
name (INC)
RING 64 64 5 MM:SS ............Minutes:Seconds
Incoming call ringing time (INC)
ACCT NO. 71 71 8 Account Code (Max. 8 digits)
2. Printout Condition
A: Outgoing call (OTG)
- Call is for Public Exchange.
- After dialing telephone number, Inter-digit timer is timeout. Inter-digit timer is assigned in Program
#27-02.
- After Inter-digit timer comes to timeout, conversation is longer than minimum time which is
assigned in Program #27-01.
- When Program #57-A is assigned "1", telephone number dialed more than digits which is assigned
in Program #59.
- The telephone must be assigned by Program #61-D = “0” (Printed).
- When conversation is transferred while Program #57-B is assigned "1", extension number of
outgoing call is printed-out.
