Nitsuko 1232 - Leave a Message (from Outside)

¾ 7-3-3-2 ¾
Features on DISA
RELATED SYSTEM DATA:
#17-E: Existance of Attendant for DISA
#66: DISA Timers
#78-E: DISA Dial Tone Assignment
RELATED FEATURES:
Direct Inward System Access (DISA)
External Call Forward on DISA Line
Night Service
n
nn
n Leave a Message (from outside)
DESCRIPTION:
On the Extension Access feature in DISA, when outside caller calls to extension which is set the Absent
Mode, outside caller hears Absent Message (Personal Message) that extension user left and VAU
Message (No. 06: Demanding message for Leave a Message), or VAU Message (No. 07: Demanding
message for Leave a Message or Telephone Number). When outside caller try to leave a message to
absent extension user, system sends Starting Message (No. 12: Starting Message for Leave a Message)
and 1-beep tone (0.5 sec./400 Hz) to outside caller. After heard this tone, outside caller can start
recording a message. Recorded messages are stored at memory area of Personal Message. Message
time is according to Personal Message time (Program #64-A). When outside caller finished recording,
system sends the Ending Message (VAU Message No. 13: Ending Message for Leave Message). Absent
Mode extension user can listen to the recorded messages after came back to the desk. After confirming
recorded message, user can also transfer the message to the other extension.
On the intercom call, when the other extension called to Absent Mode extension, system sends Absent
Message and Busy Tone. Called extension can not use Intercom Camp-On and Intercom Off-Hook
Signaling features.
Message time which outside caller can record is set in Program #64-A. Maximum 10 recorded messages
from outside are stored at each extension. When system power is in OFF condition, all Personal
Messages and recorded messages are erased. When there are some messages that outside caller left,
MW lamp/Indicator flashes as follows at Absent Mode extension.
- KTS(TD/TXD): MW lamp 0.1 sec. ON/0.1 sec. OFF
- KTS(BTD/BTXD): Indicator 0.1 sec. ON/0.1 sec. OFF
- SLT: Dial Tone 0.4 sec. ON/0.1 sec. OFF
STATION APPLICATION:
KTS, SLT
OPERATION:
To set Absent Mode:
Display Indication Operation and Information
##SUN# 25# 12:00PM
(KTS)
1. Lift handset or press SPK.
2. Press ICM key. (See Note)
3. Press TRFR.
##SUN# 25# 12:00PM
##############12
4. Dial
own
extension number.
(For Example: Extension No. 12)
