Program 4
This program assigns the following functions for each extension.
Display Indication Input Data Initial
STN# ASSIGNMENT1
#####04-ST-ABCDE
ST. Extension number (10 - System Max)
A. Break-In
0: Not allowed
1: Allowed with tone
2: Allowed without tone
B. Trunk Off-Hook Signaling
0: Disable 1: Enable
C. Intercom Off-Hook Signaling
0: None 1: When Dial 2: When Busy
D. Intercom Signal Call
0: Disable 1: Enable
E. Headset operation
0: Disable 1: Enable
(ALL)
A: 0
B: 0
C: 0
D: 0
E: 0
When extension is assigned the Signal Call mode in Program #04-D after the system has been
assigned the Voice Call mode in Program #19-B, this extension is Signal Call mode, but the other
extensions are kept the Voice Call mode.
When extension is assigned Voice Call mode in Program #04-D after the system has been assigned
the Signal Call mode in Program #19-B, all extensions are Signal Call mode regardless of Program
#04-D.
Program 5
This program assigns an extension port to an Unsupervised Conference circuit. In the TX-Z 308,
824, 1232, 2464 system, the Unsupervised Conference circuits are numbered 01-04. An extension
port assigned as an Unsupervised Conference port must not be terminated with a phone. In other
wards, Unsupervised Conference circuit
MUST BE ASSIGNED AN UNUSED EXTENSION PORT.
Display Indication Input Data Initial
UNSUP.CONF.PORT#
#######05##XX-ST
XX. Port No. (01 - 04)
(Cannot input dial)
ST. Extension port for unsupervised conference
00: Not assigned
10 - System Max: (Extension number)
* Up to 4 ports can be set in a system.
(XX =
01 - 04)
ST: 00
