Program 1
This program assigns Line Type (CO/PBX), Dial Mode (Pulse/DTMF), Queue Group, PBX Night
Mode and a Polarity Reverse Detection (only 1232/2464 system) to each outside line.
Display Indication Input Data Initial
LINE# ASSIGNMENT1
#####01-LN-ABCDE
LN. Line number (01 - System Max)
A. Line Type
0: No connection
1: CO Line
2: -- Not Used --
3: PBX Line
B. Dial Mode
0: DP (Dial Pulse) 1: DTMF
C. Queuing Group
0: Not assigned
1 - 6: Group 1 - Group 6
D. PBX Night Mode
0: Disable 1: Enable
E. Polarity Reverse Detect (Only TX-Z
1232/2464)
0: Disable 1: Enable
* When the Line is unused, the Line must be
assigned "No connection" in Line Type.
(ALL)
A: 1
B: 1
C: 1
D: 0
E: 0
Program 2
This program assigns CO/PBX lines into groups. The line groups are assigned to an extension for
Outgoing and Incoming calls. Only consecutive lines can be grouped (e.g., lines 3,4,5). Lines in one
group can overlap with lines in another.
Display Indication Input Data Initial
LINE# GROUPS#####
#####02-GP-ST-ED
GP. Line group number (01 - 30)
ST. Lowest numbered line in group
(01 - System Max)
ED. Highest numbered line in group
(01 - System Max)
(Group 1)
(308)
ST: 01
ED: 03
(824/1232/
2464)
ST: 01
ED: 08
(Other)
ST: 00
ED: 00
