Nitsuko 1232 - Inside View of the Main Unit; Name and Location; Overview of the Main Unit; Wall Mounting

¾
3-1-1
¾
Name and Location
Wall Mounting
1. Place the template (included) on the wall to mark the four
screw positions.
2. Install the four screws (included) into the wall.
3. Hook the main unit on the screw heads.
Overview of the Main Unit Inside View of the Main Unit
AC cord
Front Cover
Power Indicator
Ground Terminal
Cable Holders
Trunk 2-pin Jack
Extension 4-pin
Jacks
Initialization
Switch
