Other Intercom Features
¾ 4-53 ¾
n
nn
n DSS Console (TX-Z 1232/2464)
DESCRIPTION:
DSS Console gives an extension user a Busy Lamp Field (Idle/Busy/DND/MW) and one-button access to
extension, Doorphone or Paging. This saves time for users that do a lot of processing (e.g., Operator).
TX-Z 1232 System can connect one DSS Console. TX-Z 2464 System can connect Maximum 2 DSS
Consoles. Pair extension of each DSS Console is assigned in Program. When a DSS Console is
connected, an intercom link is used exclusively for DSS Console. The Pair extension
must be KTS
. (It is
recommended to be KTS with LCD.) Each DSS Console must be connected to the
LAST PORT
of each
unit.
DSS Console features and operations are as follows;
1. DSS Call (One-Touch Extension Access)
DESCRIPTION
User can make intercom conversation by only pressing the DSS key. Each DSS key is assigned
following extension number (which is set the in Program 14) accordingly.
(Not by physical port)
Pair
extension operated DSS Call can not use CONF, TRFR, HOLD keys within intercom conversation.
OPERATION
1. Lift handset or press SPK.
2. Press one of DSS key.
RELATED FEATURES
Intercom Calls
Flexible Station Numbering
2. Automatic Hold of Trunk Line
DESCRIPTION
When DSS Console user make conversation with Outside Caller, user can transfer this line for the
other extension. When user is transferring the Trunk Line, the Trunk Line is held automatically.
OPERATION
1. On the Trunk Line call.
2. Press one of DSS key.
RELATED FEATURES
Hold - Automatic Hold
3. Paging
DESCRIPTION
External and Internal Paging is possible by the single button operation. The following keys are used
for Paging from a DSS position. When this feature is activated, Meet-me Answer and Meet-me
Conference are disabled.
AC: All Call
IZ1: Internal Paging (For Zone 1)
IZ2: Internal Paging (For Zone 2)
IZ3: Internal Paging (For Zone 3)
IZ4: Internal Paging (For Zone 4)
EAZ: External All Paging
EZ1: External Paging (For Zone 1)
EZ2: External Paging (For Zone 2)
