System Configuration (TX-Z 824)
Name Description
Quantity
/System
Remarks
NX.E-824M TXZ ME(1) TX-Z 824 Main Equipment for 100V
NX.E-824M TXZ ME(2) TX-Z 824 Main Equipment for 200V
1
CPU, Power Supply,
battery charger, and 4-
Trunk/8-extension
interface included.
NX.E-6TD TXZ KTS
6 Line keys, standard type Key
Telephone
NX.E-6TXD TXZ KTS 6 Line keys, display type Key Telephone
NX.E-12TD TXZ KTS
12 Line keys, standard type Key
Telephone
NX.E-12TXD TXZ KTS 12 Line keys, display type Key Telephone
1st Model.
Modular station cable
included.
NX.E-6BTD TXZ KTS
6 Line keys, standard type Key
Telephone
NX.E-6BTXD TXZ KTS 6 Line keys, display type Key Telephone
NX.E-12BTD TXZ KTS
12 Line keys, standard type Key
Telephone
NX.E-12BTXD TXZ KTS 12 Line keys, display type Key Telephone
24
2nd Model.
Modular station cable
included.
NX7E-208E-A1 2-Trunk/8-extension card
NX7E-008E-A1 8-extension card
2
NX7E-4PFU-A1 4 PF transfer card 1
4 power failure transfer
circuits for SLT.
NX7E-8DHEXU-A1
Doorphone I/F, relay contacts
EXMOH/BGM input, EXP output
1
Music sources are required
for EXMOH, BGM.
NX7E-8RGU-A1 Ringer unit for Single Line Telephone 1
1 pce. for a system when
SLT is connected.
NX7E-8SMDR-A1 SMDR interface card
Needed to use SMDR
printer.
NX7E-8SMCID-A1 Caller-ID/SMDR interface card
1
Needed to use Caller-
ID/SMDR
NX7E-8CID ADAPTOR Caller-ID adapter 1
1 set for 8 Trunk lines
Complied with Bellcore
Spec.
NX.E-24DL TXZ DLS
24 key DLS Console for 1st Model Key
Telephone (used as DSS Console)
NX.E-24BDL TXZ DLS
24 key DLS Console for 2nd Model Key
Telephone (used as DSS Console)
3
Connected to display type
key telephone.
NT-S-D6 2-wire doorphone box 2 8DHEXU is required.
NVM-2 Model 1
Voice Mail with 2 ports, 2 hour voice
storage, 50 mailboxes.
As
needed
1 Voice Mail I/F is required
for 2 ports.
NVM-2 Model 2
Voice Mail with 4 ports, 4 hour voice
storage, 50 mailboxes.
As
needed
1 Voice Mail I/F is required
for 2 ports.
NVM-22
Voice Mail with 2-4 ports, 25 hour voice
storage, 50-100 mailboxes.
As
needed
1 Voice Mail I/F is required
per port.
Voice Mail I/F Voice Mail Interface Unit
As
needed
Required for VM
connection
DX2E-32i/NX7E
BATTERY BOX
External backup battery box 1
NP2.6 or equivalent
batteries are required.
To Next Page
