Other Features
n
nn
n General Message
DESCRIPTION:
Extension user can send a General Message to the other extensions or some extensions which belong to
Hunt Group. The message is recorded at the each time. Receiving extensions can listen to the sent
General Message and also can transfer to the other extension, if necessary.
If user sent a message to desired extensions, sending extension's and desired extensions' MW
lamp/Indicator flashes. If user sent a message to the desired Hunt Group, MW lamp/Indicator flashes at
all extensions which belong to Hunt Group. If desired extensions are SLT, Dial Tone changes from
continual tone to 0.4 sec. ON/0.1 sec. OFF as instead of MW lamp/Indicator.
When system power is OFF condition, all General Messages and Personal Messages will be erased.
Flashing conditions are following patterns;
- Originating Extension: 0.1 sec. ON/0.1 sec. OFF/0.1 sec. ON/0.7 sec. OFF
- Receiving extension: 0.1 sec. ON/0.1 sec. OFF
STATION APPLICATION:
KTS, SLT
OPERATION:
To record and send a General Message:
Display Indication Operation and Information
##SUN# 25# 12:00PM
STA#,HUNT#>#####
(KTS)
1. Lift handset or press SPK. (See Note 1)
2. Dial 940. (see Note 2)
##SUN# 25# 12:00PM
STA#,HUNT#>###10
3. Dial desired extension number (10 - 79/100 - 799)
or desired Hunt Group number (00 -04).
(For Example: send to extension No. 10)
00:00:00# 12:00PM
STA#,HUNT#>###10
4. Dial
*
. (Recording and timer counting start.)
5. Record a message from handset or microphone.
00:00:06# 12:00PM
STA#,HUNT#>###10
6. Dial
*
. (Recording and timer counting finish.)
(For Example: Recording time is 6 sec.)
(see Note 3)
##SUN# 25# 12:00PM
7. Hang up or press SPK.
* When user hangs up or presses SPK without dialing
*
or
#, the recorded message will be saved. When 16 sec. has
passed during message recording, timer counting will
automatically be finished and the recorded message will
be saved.
