System Programming Procedure
System Reset
Switch-2 (RST/RUN) is used to System Reset for TX-Z 824 & 1232/2464 system. Move the switch
to RST (the left) to reset the system immediately, keeping the current program.
However, Reset switch is not available for TX-Z 308 system. To reset TX-Z 308, disconnect the AC
plug and replace while the SW1 is on the
other side of INT
.
Connecting Single Line Telephone
TX-Z 308/824/1232/2464 system can connect Single Line Telephones (SLTs) without changing the
hardware but can not recognize the instrument type by only connecting the SLT. When you connect
the SLT first time, you must operate as follows so that system can recognize.
- Method-1: Off-Hook and Hang up. (Once)
- Method-2: On the Program #13-E, assign "1 => Connected".
In the each case, when SLT is disconnected, you have to assign the "0 => Not connected" in
Program #13-E.
Entering the System Data Programming
1. (On-Hook Condition) Press OPAC key.
2. Dial #, *, #, * and Password (8 digits).
3. Press HOLD key.
Password can be changed in Program #92. Password's digits are optional from 1 to 8 digits long,
and digits between 0 and 9.
When you forgot password, you can use Special Password to enter the System Data set up mode.
Key Institution
0 - 9: Enter Program number, Extension number, Trunk number and Option number, etc.
*: Go to next item.
#: Exit from current program number.
