NSK Megatorque PS Series User Manual

— 9-49 —
MW: Main Power Supply Internal Voltage Monitor
 Monitors the internal direct current voltage after commutation of the main power.
Category Monitor
Format
MW data
Data range 0.0 to 401.3 [v]
P MX: Monitor, Secondary
 Sets an item to be monitored by the MON2 (Analog monitor, secondary)
◊ Refer to ”7.4. Analog Monitor” for details.
Category Parameter
Format
MX data
Data range 1
0
1
2
3
4
5
6
7
8
: Current velocity
: Commanded velocity
: Velocity error
: Torque command
: øU current
: Transient position command
: Residual pulses in the error counter (Zoomed)
: Residual pulses in the error counter (Normal)
: Software thermal loading
Data range 2
Command
name
: Specify a monitor name, such as “MXTV”, for monitoring.
Shipping set 0
 A change of this parameter will automatically reset the parameters MXY (Monitor offset,
secondary) and MXR (Monitor range, secondary) in accordance with the specified monitor.
◊ The output offset of parameter MXY is set to a value when the monitor center is set to
2.5 [V].
◊ The output range of parameter MXR is set to a value when the maximum monitor
output is 5.0 [V].
P MXR: Monitor Range, Secondary
 This parameter specifies the monitor output range of the parameter MX (Analog monitor,
secondary).
◊ Refer to “7.4.2. Customization of Monitor Data” for details.
Category Parameter
Format
MXR data
Data range
(Depends on the setting of the
monitor MX.)
Shipping set 10.000
