— 9-64 —
TDV : (Factory use only)
This monitor is for the factory use only.
TE: Tell Position Error Counter
Monitors the state of the position error counter.
◊ Refer to “ 7.3. RS-232C Monitor” for details.
◊ The position error counter indicates the difference between the current position and the
commanded position.
Category monitor
Format
TE
Data range 0 to ± 2 621 439 [pulse]
(This is an approximate number.)
P TEO: Tell Position Error, Over
This parameter specifies the threshold for an activation of the output TEO (Position error, over).
◊ Refer to “8.3.2.1. Position Error: TEU (Position Error, Under) and TEO (Position Error,
Over)” for details.
◊ The output TEO activates when the data of the position error counter is greater or equal
to the setting of the parameter TEO.
Category Parameter
Format
TEO data
Data range 0 to 2 621 439 [pulse]
Shipping set 0
P TEU : Tell Position Error, Under
This parameter specifies the threshold for an activation of the TEU output (Position error, under)
◊ Refer to “8.3.2.1. Position Error: TEU (Position Error, Under) and TEO (Position Error,
Over)” for details.
◊ The output TEU activates when the data of the position error counter is less or equal to
the setting of the parameter TEU.
category Parameter
Format
TEU data
Data range 0 to 2 621 439 [pulse]
Shipping set 0
