— 9-70 —
TS: Tell Settings
This command monitors the parameter settings in a group.
◊ Refer to “4.3. Readout of Parameter” for details.
Category Command
Format 1
TS data
Format 2
TS data /MD
: Reads out only the parameters altered from the shipping set.
Data range 1 0
:Reads out all groups.
Data range 2 1 to 12 [Group]
: Reads out the specified group.
Table 9-7: Reading out groups by the command TS
TS Group Parameters
0
All parameters (All parameters listed below)
1
Basic servo PG, PGL, VG, VGL, FQ, LG, LB, TL, GP, GT
2
Applied servo FO, FP, FS, NP, NPQ, NS, NSQ, DBP, BL, FF, ZF
3
Positioning completion CO, IN, IS, FW
4
Pulse train input CR, PC
5
Position feedback FD, FZ, FR
6
Position scale data PS, DI, OTP, OTM, AO
7
Positioning MV, MA, MB, JV, JA, JB, HV, HA, HB, HZ, MD, CSA, CSB, QR, OE,
PK, AE
8
Home return OS, HD, HO
9
(Reserved) SQ
10
General inputs/outputs OV, BW, NA, NB, ZAS, ZAE, ZAW, ZBS, ZBE, ZBW, ZCS, ZCE, ZCW,
TEU, TEO, TVU, TVO, TVEU, TVEO, TTU, TTO, TJU, TJO, MN, MNR,
MNY, MX, MXR, MXY, POD
11
Communication MM, BM, WM, EC, MR, PP
12
Automatic tuning LO, SG, ZP
TST: Tell Settle Time
This monitor reads out the settling time by a positioning command.
◊ Refer to “7.3. RS-232C Monitor” for the details.
◊ The settling time is the time stating from an input of the internal position command to the
first completion of a positioning operation.
◊ The readout is reset at every completion of positioning operation.
Category Monitor
Format
TST
Data range 0.0 to 214 641 044.2 [ms]
TT: Tell Torque Command
This monitor reads out the torque command.
◊ Refer to “7.3. RS-232C monitor” for details.
Category Monitor
Format
TT
Data range 0.00 to ±100.00%
