96 KByte Flash Module (S12FTMRG96K1V1)
MC9S12G Family Reference Manual Rev.1.27
NXP Semiconductors 1003
28.4.6.2 Erase Verify Block Command
The Erase Verify Block command allows the user to verify that an entire P-Flash or EEPROM block has
been erased. The FCCOB FlashBlockSelectionCode[1:0] bits determine which block must be verified.
Upon clearing CCIF to launch the Erase Verify Block command, the Memory Controller will verify that
the selected P-Flash or EEPROM block is erased. The CCIF flag will set after the Erase Verify Block
operation has completed.If the block is not erased, it means blank check failed, both MGSTAT bits will be
set.
Table 28-33. Erase Verify Block Command FCCOB Requirements
CCOBIX[2:0] FCCOB Parameters
000 0x02
Flash block
selection code [1:0]
. See
Table 28-34
Table 28-34. Flash block selection code description
Selection code[1:0] Flash block to be verified
00 EEPROM
01
Invalid (ACCERR)
10
P-Flash
11
P-Flash
Table 28-35. Erase Verify Block Command Error Handling
Register Error Bit Error Condition
FSTAT
ACCERR
Set if CCOBIX[2:0] != 000 at command launch
Set if an invalid FlashBlockSelectionCode[1:0] is supplied
1
1
As defined by the memory map for FTMRG96K1.
FPVIOL None
MGSTAT1 Set if any errors have been encountered during the read
2
or if blank check failed.
2
As found in the memory map for FTMRG96K1.
MGSTAT0
Set if any non-correctable errors have been encountered during the read
2
or if
blank check failed.
