Device Overview MC9S12G-Family
MC9S12G Family Reference Manual Rev.1.27
40 NXP Semiconductors
0x000A–0x000B MMC (Memory Map Control) 2
0x000C–0x000D PIM (Port Integration Module) 2
0x000E–0x000F Reserved 2
0x0010–0x0017 MMC (Memory Map Control) 8
0x0018–0x0019 Reserved 2
0x001A–0x001B Device ID register 2
0x001C–0x001F PIM (Port Integration Module) 4
0x0020–0x002F DBG (Debug Module) 16
0x0030–0x0033 Reserved 4
0x0034–0x003F CPMU (Clock and Power Management) 12
0x0040–0x006F TIM (Timer Module <= 8 channels) 48
0x0070–0x009F ADC (Analog to Digital Converter <= 16 channels) 48
0x00A0–0x00C7 PWM (Pulse-Width Modulator <= 8 channels) 40
0x00C8–0x00CF SCI0 (Serial Communication Interface) 8
0x00D0–0x00D7 SCI1 (Serial Communication Interface)
1
8
0x00D8–0x00DF SPI0 (Serial Peripheral Interface) 8
0x00E0–0x00E7 Reserved 8
0x00E8–0x00EF SCI2 (Serial Communication Interface)
2
8
0x00F0–0x00F7 SPI1 (Serial Peripheral Interface)
3
8
0x00F8–0x00FF SPI2 (Serial Peripheral Interface)
4
8
0x0100–0x0113 FTMRG control registers 20
0x0114–0x011F Reserved 12
0x0120 INT (Interrupt Module) 1
0x0121–0x013F Reserved 31
0x0140–0x017F CAN
5
64
0x0180–0x023F Reserved 192
0x0240–0x025F PIM (Port Integration Module) 32
0x0260–0x0261 ACMP (Analog Comparator)
6
2
0x0262–0x0275 PIM (Port Integration Module) 20
0x0276 RVA (Reference Voltage Attenuator)
7
1
0x0277–0x027F PIM (Port Integration Module) 9
0x0280–0x02EF Reserved 112
0x02F0–0x02FF CPMU (Clock and Power Management) 16
0x0300–0x03BF Reserved 192
0x03C0–0x03C7 DAC0 (Digital to Analog Converter)
8
8
Address Module
Size
(Bytes)
