Digital Analog Converter (DAC_8B5V)

MC9S12G Family Reference Manual Rev.1.27

NXP Semiconductors 567

See Table 17-8 for an example for VRL = 0.0 V and VRH = 5.0 V.

Table 17-8. Analog output voltage calculation

FVR min. voltage

max.

voltage

Resolution Equation

0 0.5V 4.484V 15.625mV VOLTAGE[7:0] x (4.0V) / 256) + 0.5V

1 0.0V 4.980V 19.531mV VOLTAGE[7:0] x (5.0V) / 256
