48 KByte Flash Module (S12FTMRG48K1V1)
MC9S12G Family Reference Manual Rev.1.27
908 NXP Semiconductors
Upon clearing CCIF to launch the Set User Margin Level command, the Memory Controller will set the
user margin level for the targeted block and then set the CCIF flag.
NOTE
When the EEPROM block is targeted, the EEPROM user margin levels are
applied only to the EEPROM reads. However, when the P-Flash block is
targeted, the P-Flash user margin levels are applied to both P-Flash and
EEPROM reads. It is not possible to apply user margin levels to the P-Flash
block only.
Valid margin level settings for the Set User Margin Level command are defined in Table 26-55.
NOTE
User margin levels can be used to check that Flash memory contents have
adequate margin for normal level read operations. If unexpected results are
encountered when checking Flash memory contents at user margin levels, a
potential loss of information has been detected.
Table 26-55. Valid Set User Margin Level Settings
CCOB
(CCOBIX=001)
Level Description
0x0000 Return to Normal Level
0x0001 User Margin-1 Level
1
1
Read margin to the erased state
0x0002 User Margin-0 Level
2
2
Read margin to the programmed state
Table 26-56. Set User Margin Level Command Error Handling
Register Error Bit Error Condition
FSTAT
ACCERR
Set if CCOBIX[2:0] != 001 at command launch
Set if command not available in current mode (see Table 26-27)
Set if an invalid FlashBlockSelectionCode[1:0] is supplied (See Table 26-34 )
Set if an invalid margin level setting is supplied
FPVIOL None
MGSTAT1 None
MGSTAT0 None
