96 KByte Flash Module (S12FTMRG96K1V1)
MC9S12G Family Reference Manual Rev.1.27
986 NXP Semiconductors
Trying to alter data in any protected area in the P-Flash memory will result in a protection violation error
and the FPVIOL bit will be set in the FSTAT register. The block erase of a P-Flash block is not possible if
any of the P-Flash sectors contained in the same P-Flash block are protected.
Table 28-17. FPROT Field Descriptions
Field Description
7
FPOPEN
Flash Protection Operation Enable — The FPOPEN bit determines the protection function for program or
erase operations as shown in Table 28-18 for the P-Flash block.
0 When FPOPEN is clear, the FPHDIS and FPLDIS bits define unprotected address ranges as specified by the
corresponding FPHS and FPLS bits
1 When FPOPEN is set, the FPHDIS and FPLDIS bits enable protection for the address range specified by the
corresponding FPHS and FPLS bits
6
RNV[6]
Reserved Nonvolatile Bit — The RNV bit should remain in the erased state for future enhancements.
5
FPHDIS
Flash Protection Higher Address Range Disable — The FPHDIS bit determines whether there is a
protected/unprotected area in a specific region of the P-Flash memory ending with global address 0x3_FFFF.
0 Protection/Unprotection enabled
1 Protection/Unprotection disabled
4–3
FPHS[1:0]
Flash Protection Higher Address Size — The FPHS bits determine the size of the protected/unprotected area
in P-Flash memory as shown inTable 28-19. The FPHS bits can only be written to while the FPHDIS bit is set.
2
FPLDIS
Flash Protection Lower Address Range Disable — The FPLDIS bit determines whether there is a
protected/unprotected area in a specific region of the P-Flash memory beginning with global address 0x3_8000.
0 Protection/Unprotection enabled
1 Protection/Unprotection disabled
1–0
FPLS[1:0]
Flash Protection Lower Address Size — The FPLS bits determine the size of the protected/unprotected area
in P-Flash memory as shown in Table 28-20. The FPLS bits can only be written to while the FPLDIS bit is set.
Table 28-18. P-Flash Protection Function
FPOPEN FPHDIS FPLDIS Function
1
1
For range sizes, refer to Table 28-19 and Table 28-20.
1 1 1 No P-Flash Protection
1 1 0 Protected Low Range
1 0 1 Protected High Range
1 0 0 Protected High and Low Ranges
0 1 1 Full P-Flash Memory Protected
0 1 0 Unprotected Low Range
0 0 1 Unprotected High Range
0 0 0 Unprotected High and Low Ranges
