Basic copy operations
3-52 CS193/CS173/CS163
– If the binding position for the original is set to "Auto", the position of the binding margin is
automatically selected. A binding margin along the long side of the paper is selected if the original
length is 297 mm or less. If the original length is more than 297 mm, a binding margin along the short
side of the paper is selected.
– If "Auto" is selected under "Original Bind Direction", the binding margin is set at the top or at the left.
– For a double-sided original, touch [Binding Position], select the binding position of the original, and
then touch [OK].
3 Touch [Original Direction], select the orientation of the loaded original, and then touch [OK].
– For details on specifying the original orientation, refer to "Selecting the original orientation (Original
Direction settings)" on page 3-24.
4 Touch [OK].
The Basic screen appears again.
