Oce CS193 - Clearing a Paper Misfeed in the Fusing Unit

5
Troubleshooting
5-20 CS193/CS173/CS163
5.2.8 Clearing a paper misfeed in the fusing unit
!
Detail
For details on the positions of paper misfeeds, refer to "Paper misfeed indications" on page 5-6.
1 Pull up the upper right-side door release lever, and then open
the upper right-side door.
2 Slowly remove any misfed paper from the fusing unit.
– Pull down any misfed paper from the fusing unit.
– Toner that did not pass through the fusing unit may get on
your hands or clothes. Be extremely careful when
removing the paper.
– If the paper cannot be removed by pulling it down, open
the fusing unit, and then pull it up.
– If the paper is zigzag folded and jammed in the fusing unit,
open the fusing unit, and then remove the paper.
