4535 612 10261 HD11 Service Manual Page 131
CSIP Level 1 Performance Tests: Test and Inspection Matrices
Sep:
Safety—
Epiaortic
Transducer/
Interoperative
(CF Type)
Measure the leakage current of the CF
transducer using test setup described in
“Electrical Safety Tests” on page 143.
(x) Leakage current, source (single fault)
(y) Leakage current, sink (mains voltage
applied)
(x) < 50 μA (UL/IEC/CSA)
(y) < 50 μA (UL/IEC/CSA)
If transducer is within the
above limits, the transducer
or PIU passes, and you
record test data.
Sep(sn):P/x/y
or
Sep(sn):F/x/y
(x and y = μA
measured, sn = last 5
digits of serial number,
P= Pass and F= Fail)
Ti:
(All models of
imaging
transducers)
Are transducer and lens free from cuts, or
other physical damage?
Answer to question is “yes.”
(If so, perform the next
inspection.)
(See “Important Condition:”
on page 133.)
Table 6-1 HD11 System Test and Inspection Matrix (Continued)
Test Block
Name
(or Symbol)
Test or Inspection to Perform Expected Test Results
What to Record on
Service Record
To Next Page
