4535 612 10261 HD11 Service Manual Page 134
CSIP Level 1 Performance Tests: Test and Inspection Matrices
P:
(Printers, all
models)
Using the system controls, make a test print
of the initial imaging screen:
Compare the print to the screen. Does all
of the information presented on the screen
and print match?
Answer to question is “yes.”
(If so, perform next
inspection.)
Are the printout characters in focus? Answer to question is “yes.”
(If so, perform next
inspection.)
Do all of the printer controls operate as
intended?
Answer to question is “yes.”
(If so, perform next
inspection.)
Inspect the printout. Is it free from
scratches, missing pixels, lines, indications of
noise, or any other disfigurement that
would alter the image?
Answer to question is “yes.”
If all answers are “yes,” the
printer passes.
P:P
or
P:F
(P = Pass and F = Fail)
V:
(VCRs, all
models)
On the ultrasound system, tape at least
30 seconds of any live color image and
30 seconds of any black-and-white image
with Audio:
Table 6-1 HD11 System Test and Inspection Matrix (Continued)
Test Block
Name
(or Symbol)
Test or Inspection to Perform Expected Test Results
What to Record on
Service Record
