4535 612 10261 HD11 Service Manual Page 135
CSIP Level 1 Performance Tests: Test and Inspection Matrices
Did all of the information that was showing
on the system screen record on the video
tape?
Answer to question is “yes.”
(If so, perform next
inspection.)
During playback, was the image in focus and
easy to view without distortion (no excess
snow, jitter, or noise)?
Answer to question is “yes.”
(If so, perform next
inspection.)
Were all of the colors in playback shown on
the color bar?
Answer to question is “yes.”
(If so, perform next
inspection.)
Do all of the VCR control functions operate
properly? (Start/Stop/FF/Rew/Reset/Search,
and so on)
Answer to question is “yes.”
(If so, perform next
inspection).
Can playback audio be heard on speakers? Answer to question is “yes.”
If all answers were yes, the
VCR passes.
V:P
or
V:F
(P = Pass and F = Fail)
Xp:
(PC)
When the system is powered on, did the
system arrive at initial imaging screen
without reporting errors?
Answer to question is “yes.”
(If so, perform next
inspection.)
Table 6-1 HD11 System Test and Inspection Matrix (Continued)
Test Block
Name
(or Symbol)
Test or Inspection to Perform Expected Test Results
What to Record on
Service Record
To Next Page
