4535 612 10261 HD11 Service Manual Page 136
CSIP Level 1 Performance Tests: Test and Inspection Matrices
Do all of the devices in, or connected to,
the PC work as intended?
(keyboard, trackball, CD, MOD)
Answer to question is “yes.”
If answer to this and previous
question is “yes,” PC test
passes.
Xp:P
or
Xp:F
(P=Pass and F = Fail)
X:
(software)
In the Setup window, click the Options
tab. Then click Options and view the
Software Revision number in the title bar of
the dialog box. Is the software revision
number correct?
If answer to question is “yes,”
software test passes.
X:P
or
X:F
(P=Pass and F = Fail)
C:
(Cart: power
cord, wheels,
cart, keyboard,
monitor)
Are the power cord and on/off switch in
good physical condition and working
properly?
Answer to question is “yes.”
(If so, perform next
inspection.)
Table 6-1 HD11 System Test and Inspection Matrix (Continued)
Test Block
Name
(or Symbol)
Test or Inspection to Perform Expected Test Results
What to Record on
Service Record
To Next Page
