4535 612 10261 HD11 Service Manual Page 395
CSIP Level 1 Parts: Parts List
65 Figure 14-16 453561194831 PCB Assy, PCA, Hauppauge
Video Capture
PC assembly
See Figure 13-1 for PCB
locations
66 Figure 14-16
M2540-67110
1
453561194321
1
PCB Assy, PC Motherboard PC assembly
See Figure 13-1 for PCB
locations
67 Figure 14-16 453561194361 PCB Assy, PCA, PCI, SGL
Serial Port
PC assembly
See Figure 13-1 for PCB
locations
68 Figure 14-16 453561180551 PCB Assy, Sound Card,
Creative CT4751
PC assembly
See Figure 13-1 for PCB
locations
69 Figure 14-16 453561194841 PCB Assy, PCA, TVIEW
Video Converter
PC assembly
See Figure 13-1 for PCB
locations
70 Figure 14-18 453563499311 PCB Assy, 3D Motor
Controller
(Galil Motion Control)
E-box assembly
See Table 14-2 for option
kits
See Figure 13-2 for PCB
locations
Table 14-1 HD11 Ultrasound System Parts List (Continued)
Item
No.
Located
On
Legacy
Part Number
12NC
Part Number Part Description Notes/Reference
