4535 612 10261 HD11 Service Manual Page 396
CSIP Level 1 Parts: Parts List
71 Figure 14-17 M2540-60210 453561125671 PCB Assy, Backplane Board E-box assembly
See Figure 13-2 for PCB
locations
72 Figure 14-17 M2540-60220 453561125661 PCB Assy, Signal
Distribution Board
E-box assembly
See Figure 13-2 for PCB
locations
73 Figure 14-18 M2540-60260 453561125621 PCB Assy, Signal Processor
Board
E-box assembly
See Figure 13-2 for PCB
locations
74 Figure 14-18 M2540-60240 453561125641 PCB Assy, Transmit and
Receive (TR) Board
E-box assembly
4 boards required, TR0,
TR1, TR2, TR3
See Figure 13-2 for PCB
locations
75 Figure 14-20 M2540-60190 453561125681 PCB Assy, Video I/O Board Rear I/O panel
76 Figure 14-14
Figure 14-15
453561152641 PC, Display Processor,
HD11 SCD
HD11 PC assembly
77 Figure 14-15 453561194311 Power Supply, PC, Switching,
6 Output, 300W
Top rear of PC assembly
78 Figure 14-19 453561161891 Power Supply, Universal DC
and AC, HD11
Bottom of E-box assembly
Table 14-1 HD11 Ultrasound System Parts List (Continued)
Item
No.
Located
On
Legacy
Part Number
12NC
Part Number Part Description Notes/Reference
