4535 612 10261 HD11 Service Manual Page 397
CSIP Level 1 Parts: Parts List
79 Figure 14-17 453561188621 Screw, M3-,5x8, Pnh, Torx,
with CCC Washer, Pas
Used on the Signal
Distribution and Backplane
boards
80 Figure 14-9
0515-0430
1
No part number
as of 12/9/04
Screw, M3x0.5, 6mm-Long,
Machine
81 Figure 14-7
Figure 14-11
Figure 14-27
453561125331 Screw, M4-0.7x10, Sems,
Torx, Dr, Pan, Ss, Pas
Common usage
throughout system
See Table 14-2 for option
kits
There are two screws at
the rear of both side
panels.
82 Figure 14-11
0515-1269
1
No part number
as of 12/9/04
Screw, M4x0.7, 10mm-Long,
Machine
Used for the front and
rear cable hooks
83 Figure 14-7
Figure 14-21
0515-2859
1
No part number
as of 12/9/04
Screw, M4x0.7, 10mm-Long,
Pnh, Machine
84 Figure 14-12
Figure 14-27
M2540-80320
1
No part number
as of 12/9/04
Screw, M4x0.7, 10mm-Long,
w/Washer, Mushroom,
Machine
Also used as part of config
kit 989605346371
85 Figure 14-8
Figure 14-11
453561184181 Screw, M4x30, Tx, Flh, Pas,
Ss, Patch
Control panel screws
Table 14-1 HD11 Ultrasound System Parts List (Continued)
Item
No.
Located
On
Legacy
Part Number
12NC
Part Number Part Description Notes/Reference
