4535 612 10261 HD11 Service Manual Page 47
CSIP Level 1 System Specifications: System PC Specifications
PC Power Cable Custom Philips cable that plugs into front panel
header on motherboard; drive bay power plug;
switch on rear panel and 9-pin sub-D connector
on rear panel.
Additional PCI boards installed From the Top Down:
Radeon 7,000 64-MB AGP card in the AGP slot
Focus TVIEW Gold PCI card (S-Video jack
connected to PCI bracket with 0.5-in x 1-in piece
of 3M #1345 HD 2172-05 tape)
SIIG Cyber Serial card ā Single Fast 16550 Serial
Port
Hauppauge Video Input card (S-Video jack
connected to PCI bracket with 0.5-in x 1-in piece
of 3M #1345 HD 2172-05 tape)
Blank ā we install our E-box Interface Board here
Creative SB0229 Sound Card
Table 2-1 PC Hardware Specifications (Continued)
Component Description
