VTrak E-Class Product Manual
30
Figure 18.SAS Cascaded data connections
In the diagram above, the E310s model is shown. Connections for the E610s are
the same.
Important
For multipathing (MPIO) applications, see:
“Appendix B: Multipathing on Windows” on page 367
“Appendix C: Multipathing on Linux” on page 389
Mgmt
UPS
115200
8 N 1
Mgmt
UPS
115200
8 N 1
Mgmt
UPS
115200
8 N 1
O
I
O
I
O
I
SAS data port
E310s
SAS data/
cascade port
E310s
E310s
Host PC or Server
SAS data port
SAS data/
cascade port
SAS data port
