Promise Technology VTRAK E610f User Manual

Chapter 2: VTrak Installation
31
Figure 19.SAS Cascaded management and data connections
In the diagram above, the E310s model is shown. Connections for the E610s are
the same.
Important
For multipathing (MPIO) applications, see:
• “Appendix B: Multipathing on Windows” on page 367
• “Appendix C: Multipathing on Linux” on page 389
Mgmt
UPS
115200
8 N 1
Mgmt
UPS
115200
8 N 1
Mgmt
UPS
115200
8 N 1
O
I
O
I
O
I
O
I
O
I
O
I
Host PC or Server
VTrak
Network Switch
VTrak
VTrak
