Renesas RL78/G15

RL78/G15 CHAPTER 4 PORT FUNCTIONS
R01UH0959EJ0110 Rev.1.10 Page 108 of 765
Mar 7, 2023
20-pin products
Symbol 7 6 5 4 3 2 1 0 Address After reset R/W
PU0 PU07 PU06 PU05 PU04 PU03 PU02 PU01 PU00 F0030H 00H R/W
PU2 0 0 0 0 PU23 PU22 PU21 PU20 F0032H 00H R/W
PU4 0 0 0 0 0 0 PU41 PU40 F0034H 01H R/W
PU12 0 0
PU125
Note 1
0 0 PU122 PU121 0 F003CH 20H R/W
PUmn Pmn pin on-chip pull-up resistor selection
0 On-chip pull-up resistor not connected
1 On-chip pull-up resistor connected
Note 1. This bit can be only manipulated when the P125/INTP1/(VCOUT0)/(VCOUT1)/(SI01) pin is selected
(PORTSELB = 0) (the on-chip pull-up resistor is always valid (PU125 = 1) when the RESET
¯¯¯¯¯¯
input
(PORTSELB = 1) is selected).
Remark m = 0, 2, 4, 12
n = 0 to 7
Caution Be sure to set bits that are not mounted to their initial values.

