RL78/G15 CHAPTER 6 TIMER ARRAY UNIT

R01UH0959EJ0110 Rev.1.10 Page 220 of 765

Mar 7, 2023

Figure 6-34. Set/Reset Timing Operating Status

(1) Basic operation timing

TCLK

INTTMmn

Internal reset signal

TOmn pin/

TOmn

Internal set signal

INTTMmp

Internal reset signal

TOmp pin/

TOmp

Slave

channel

Master

channel

ToggleToggle

1 clock delay

Set SetReset

(2) Operation timing when 0% duty

TCLK

INTTMmn

Internal reset signal

TOmn pin/

TOmn

Internal set signal

INTTMmp

Internal reset signal

TOmp pin/

TOmp

Slave

channel

Master

channel

Toggle

1 clock delay

Reset has priority.

0000 0001……………………………………………………… 0000 0001

TCRmp

Reset has priority.

(Remarks are listed on the next page.)
