RL78/G15 CHAPTER 6 TIMER ARRAY UNIT

R01UH0959EJ0110 Rev.1.10 Page 230 of 765

Mar 7, 2023

Figure 6-42. Example of Set Contents of Registers During Operation as Interval Timer/Square Wave Output (2/2)

(b) Timer output register m (TOm)

Bit n

TOm TOmn

0: Outputs 0 from TOmn.

1: Outputs 1 from TOmn.

1/0

Bit n

TOEm

0: Stops the TOmn output operation by counting operation.

1: Enables the TOmn output operation by counting operation.

1/0

(d) Timer output level register m (TOLm)

Bit n

TOLm

TOLmn

0: Cleared to 0 when TOMmn = 0 (master channel output mode).

(e) Timer output mode register m (TOMm)

Bit n

TOMm

0: Sets master channel output mode.

Remark m: Unit number (m = 0), n: Channel number (n = 0 to 7)
