RL78/G15 CHAPTER 6 TIMER ARRAY UNIT

R01UH0959EJ0110 Rev.1.10 Page 232 of 765

Mar 7, 2023

Figure 6-43. Operation Procedure of Interval Timer/Square Wave Output Function (2/2)

Software Operation Hardware Status

TAU stop To hold the TOmn pin output level

Clears the TOmn bit to 0 after the value to be held

is set to the port register.

When holding the TOmn pin output level is not

necessary

Setting not required.

The TOmn pin output level is held by port function.

The TAUmEN bit of the PER0 register is cleared

to 0.

Power-off status

All circuits are initialized and SFR of each channel

is also initialized.

(The TOmn bit is cleared to 0 and the TOmn pin is

set to port mode.)

Remark m: Unit number (m = 0), n: Channel number (n = 0 to 7)
