RL78/G15 CHAPTER 6 TIMER ARRAY UNIT

R01UH0959EJ0110 Rev.1.10 Page 266 of 765

Mar 7, 2023

Figure 6-67. Example of Set Contents of Registers When One-Shot Pulse Output Function Is Used

(Slave Channel) (2/2)

(b) Timer output register m (TOm)

Bit p

TOm TOmp

0: Outputs 0 from TOmp.

1: Outputs 1 from TOmp.

1/0

Bit p

TOEm

0: Stops the TOmp output operation by counting operation.

1: Enables the TOmp output operation by counting operation.

1/0

(d) Timer output level register m (TOLm)

Bit p

TOLm

TOLmp

0: Positive logic output (active-high)

1: Negative logic output (active-low)

1/0

(e) Timer output mode register m (TOMm)

Bit p

TOMm

1: Sets the slave channel output mode.

Remark m: Unit number (m = 0), n: Master channel number (n = 0, 2, 4, 6)

p: Slave channel number (n < p ≤ 7)
