RL78/G15 CHAPTER 6 TIMER ARRAY UNIT
R01UH0959EJ0110 Rev.1.10 Page 297 of 765
Mar 7, 2023
Figure 6-83. Operation Procedure of Two-channel Input with One-shot Pulse Output Function (1/2)
Software Operation Hardware Status
TAU
default
setting
Power-off status
(Clock supply is stopped and writing to SFR of the
TAU is disabled.)
Sets the TAU0EN bit of peripheral enable registers 0
(PER0) to 1 (when the TAU0EN bit is 0, read/write
operation is disabled).
Power-on status. Each channel stops operating.
(Clock supply is started and writing to SFR of the TAU
is enabled.)
Sets timer clock select register 0 (TPS0).
Determines operation clock (CK00 and CK01) for
each channel.
Channel
default
setting
Sets noise filter enable register 1 (NFEN1).
Sets timer mode register 0n, p (TMR0n, TMR0p)
(determines operation mode for each channel and
selects the detection edge).
Channel stops operating.
Sets master channel
Sets delay (output delay time) to timer data
register 0n (TDR0n) (for the access procedure to
the TDR0nH and TDR0nL registers, see 6.2.2
Timer data register mn (TDRmn).Clears the
target bit of timer output mode register 0 (TOM0)
to 0 (master channel output mode).
Clears the target bit of the TOL0 register to 0.
Clears the target bit of the timer output enable
register 0 (TOE0) to 0.
Sets slave channel.
Sets the target bit of timer output mode register 0
(TOM0) to 1 (slave channel output mode).
Sets the target bit of the TOL0 register.
Sets the TO0p bit and determines default level of
the TO0p output.
The TO0p pin goes into Hi-Z state.
(The port mode register is set to input mode.)
Sets the TOE0p bit to 1 and enables operation of
TO0p.
Clears the port register and port mode register to 0
(output mode is set).
TO0p does not change because channel stops
operating (The TO0p pin is not affected even if the
TO0p bit is modified).
The level set in the TO0p bit is output from the TO0p
pin.
Remark n: Master channel number (n = 0, 2)
p: Slave channel number (p = 3)
