Renesas RL78/G15 User Manual

RL78/G15 CHAPTER 12 SERIAL ARRAY UNIT
R01UH0959EJ0110 Rev.1.10 Page 441 of 765
Mar 7, 2023
Figure 12-56. Procedure for Resuming Slave Reception
Starting setting for resumption
Completing resumption setting
Wait until stop the communication target (master) or
operation completed
Enable clock output of the target channel by setting
a port register and a port mode register
.
Set the SSmn bit of the target channel to 1 (SEmn
bit = 1: to enable operation
). Wait for a clock from
the master.
Completing master
preparations?
No
Yes
(Essential)
(Essential)
(Essential)
Changing setting of the SPSm
register
Changing setting of the SMRmn
register
Changing setting of the SCRmn
register
Port manipulation
Writing to the SSm register
Port manipulation
(Essential)
(Selective
)
(Selective)
(Selective)
Disable data output of the target channel by setting a port
register and a port mode register.
Re
-
set the register to change the operation clock setting.
Re-set the register to change serial mode register mn
(SMRmn) setting.
Re-set the register to change serial communication
operation setting register mn (SCRmn) setting.
Clearing error flag
If the OVF flag remains set, clear this using serial flag
clear trigger register mn (SIRmn).
(Selective)
Remark If PER0 is rewritten while stopping the communication to reset the serial array unit, wait until the
communication target (master) stops or communication finishes, and then perform initialization instead of
restarting the communication.
