RL78/G15 CHAPTER 12 SERIAL ARRAY UNIT

R01UH0959EJ0110 Rev.1.10 Page 442 of 765

Mar 7, 2023

(3) Processing flow (in single-reception mode)

Figure 12-57. Timing Chart of Slave Reception (in Single-Reception Mode) (Type 1: DAPmn = 0, CKPmn = 0)

Shift

Slp pin

SCKp pin

Data receptionData receptionData reception

SSmn

STmn

SEmn

SDRmn

INTCSIp

TSFmn

Receive data 1 Receive data 2

Receive data 1 Receive data 2 Receive data 3

Reception & shift operation Reception & shift operation Reception & shift operation

Receive data 3

ReadRead Read

Remark m: Unit number (m = 0), n: Channel number (n = 0, 1), p: CSI number (p = 00, 01), mn = 00, 01
