RL78/G15 CHAPTER 16 RESET FUNCTION

R01UH0959EJ0110 Rev.1.10 Page 640 of 765

Mar 7, 2023

Table 16-2. State of Hardware After Receiving a Reset Signal

Hardware After Reset Acknowledgment

Note 1

Program counter (PC) The contents of the reset vector table (00000H, 00001H) are set.

Stack pointer (SP) Undefined

Program status word (PSW) 06H

RAM Data memory Undefined

General-purpose registers Undefined

Note 1. During reset signal generation or oscillation stabilization time wait, only the PC contents among the hardware

statuses become undefined. All other hardware statuses remain unchanged after reset.

Remark For the state of the special function register (SFR) after receiving a reset signal, see 3.1.4 Special function
