● 11: Converter overload pre-warning
See chapter "Overload pre-warning" on page 199.
● 12: Motor overload pre-warning
See chapter "Motor overload pre-warning" on page 207.
● 13: Converter stop by external error
See chapter "Reaction to External Error Signals" on page 204.
● 14: Converter error
The output is active when an error occurs, inactive when the error is reset,
see chapter 13.4 "Error Code" on page 242.
● 15: Converter OK
The output is inactive when the frequency converter is powered off or en-
counters error / warning during running. The output is active when the fre-
quency converter is powered on but not running, or the frequency converter
is running without error / warning.
● 16: Counter target value arrival; 17: Counter middle value arrival
Used for the counter function, see chapter 12.7.1 "Counter Function" on page
172.
● 18: PID reference engineering value arrival
Used for PID function, see chapter 12.9 "PID Control" on page 186.
● 19: Pulse output mode enable (only available with DO1 output selection)
See 'Step 2: Use DO1 in pulse output mode'.
● 20: Torque control mode
See chapter "Torque control mode" on page 226.
● 99: Inactive
Step 2: Use DO1 in pulse output mode
Code
Name Setting range Default Min. Attri.
E2.01 DO1 output setting 19: Pulse output mode 0 – Stop
E2.02 DO1 pulse output setting
0: Converter output frequency
1: Converter output voltage
2: Converter output current
0 – Stop
E2.03 Pulse output maximum frequency 0.1...32.0 kHz 32.0 0.1 Run
Digital output status is monitored by parameter d0.45 'DO1 output'.
Bosch Rexroth AG
Functions and Parameters
EFC x610 Series
112/389
DOK-RCON03-EFC-X610***-IT05-EN-P
