Code Name Setting range Default Min. Attri.
E0.25
Acceleration / deceleration
curve mode
0: Linear mode
1: S-curve
0 – Stop
E0.28 S-curve starting phase factor 0.0...40.0 % 20.0 0.1 Stop
E0.29 S-curve stopping phase factor 0.0...40.0 % 20.0 0.1 Stop
[E0.25] = 0: Linear mode
Fig. 12-19: Linear mode acceleration and deceleration
Bosch Rexroth AG
Functions and Parameters
EFC x610 Series
144/389
DOK-RCON03-EFC-X610***-IT05-EN-P
