Code Name Setting range Default Min. Attri.
H8.05 EAI input mode
0: 0…20 mA
1: 4...20 mA
2: 0…10 V
3: 0...5 V
4: 2…10 V
5: -10...10 V
0 – Stop
E2.25 AO1 output mode
0: 0…10 V
1: 0…20 mA
0 – Run
E2.26 AO1 output setting
11: Motor temperature
sensor power supply
0 – Run
H8.26 EAO output selection 0 – Run
H8.25 EAO output mode
0: 0…10 V
1: 0…20 mA
0 – Run
C1.73 Motor thermal sensor protection level 0.0...10.0 V 2.0 0.1 Stop
C1.74
Motor thermal model protection time
constant
0.0...400.0 min DOM 0.1 Stop
E1.69 Analog input filter time 0.000...2.000 s 0.100 0.001 Run
Activate the function of temperature monitoring with temperature sensor:
●
Set [E1.60] = '1: AI1 analog input' or
● Set [E1.60] = '2: AI2 analog input' or
● Set [E1.60] = '3: EAI analog input'
AI1 / AI2 / EAI will be automatically set as voltage input mode when
[E1.60] = 1 or 2 or 3.
Select the sensor type:
● [C1.72] = 0: PTC, KTY84/130
For PTC or KTY84/130 sensors, the value of resistor R in the figure should be
close to the sensor resistance when the motor is at high temperature.
● [C1.72] = 2: PT100
For a good resolution of temperature with PT100 sensors, the value of resis-
tor R in the figure should be close to the sensor resistance at the motor tem-
perature limit.
● [C1.72] = 3: PT1000
For PT1000 sensors, the relationship between the resistor R and the motor
temperature is:
-30 ℃: 882 Ω
0 ℃: 1,000 Ω
EFC x610 Series
Bosch Rexroth AG
Functions and Parameters
DOK-RCON03-EFC-X610***-IT05-EN-P
209/389
