5.System Maintenance
186
Press to scroll to the previous or next line (line by line).
Press to move the highlight on the left to the previous or next selection in the list.
Switching Between SP Mode and Copy Mode for Test Printing
1. In the SP mode, select the test print. Then press "Copy Window".
2. From the copier screen (copier mode), select the appropriate settings (such as paper size) for the test print.
3. Press the [Start] key to start the test print.
4. Press SP Mode (highlighted) to return to the SP mode screen and repeat from Step 1.
Selecting the Program Number
Program numbers have two or three levels.
1. Refer to the Service Tables to find the SP that you want to adjust before you begin.
2. Press the Group number on the left side SP Mode window that contains the SP that you want to adjust.
3. Use the scrolling buttons in the center of the SP mode window to show the SP number that you want to open. Then
press that number to expand the list.
4. Use the center touch-panel buttons to scroll to the number and title of the item that you want to set and press it. The
small entry box on the right activates and shows the below default or the current settings.
ï‚· Refer to the Service Tables for the range of allowed settings.
5. Do this procedure to enter a setting:
ï‚· Press [./*] to toggle between plus and minus and use the keypad to enter the appropriate number. The
number you enter writes over the previous setting.
ï‚· Press [#] to enter the setting. (The value is not registered if you enter a number that is out of range.)
ï‚· Press "Yes" when you are prompted to complete the selection.
6. If you need to perform a test print, press Copy Window to open the copy window and select the settings for the
test print. Press [Start] key and then press SP Mode (highlighted) in the copy window to return to the SP mode
display.
7. Press Exit two times to return to the copy window when you are finished.
