4.Service Tables
43
on Quick/Speed Dial Lists
0: Disabled
1: Enabled
TX parameters (10 bytes each).
The first 10 bytes of data are the programmed dedicated TX parameters;
34 bytes of data are printed (the other 24 bytes have no use for service
technicians).
4-
7
Not used
Do not change these settings.
System Switch 05 - Not used (Do not change the factory settings.)
System Switch 06 - Not used (Do not change the factory settings.)
System Switch 07 - Not used (Do not change the factory settings.)
System Switch 08 - Not used (Do not change the factory settings.)
System Switch 09 (SP No. 1-101-010)
No
Function
Comments
0
Addition of image data from confidential
transmissions on the transmission result
report
0: Disabled 1: Enabled
If this feature is enabled, the top half of the first page of
confidential messages will be printed on transmission result reports.
1
Print timing of communication reports on
the Journal when no image data was
exchanged.
0: After DCS/NSS communication
(default),
1: After polling
0: The Journal is printed only when image data is sent.
1: The Journal is printed when any data is sent.
2
Automatic error report printout
0: Disabled 1: Enabled
0: Error reports will not be printed.
1: Error reports will be printed automatically after failed
communications.
3
Printing of the error code on the error
report
0: No 1: Yes
1: Error codes are printed on the error reports.
This can be used for detecting an error which occurs rarely.
4
Not used
Do not change this setting.
5
Power failure report
0: Disabled
1: Enabled (default)
1: A power failure report will be automatically printed after the
power is turned ON if a fax message disappeared from the
memory when the power was turned off last.
NOTE: If "0" is selected, no reports are printed and no one may
recognize that fax data is gone due to a power failure.
6
Conditions for printing the protocol
dump list
This switch becomes effective only when system switch 00 bit 6 is
set to 1.
