4.Service Tables
95
Address
Function
Unit
Remarks
68054D
Time between final OHDI relay closure
and DO relay opening or closing
1 ms
See Notes 3, 6 and 8.
SP2-103-015 (parameter 14).
This parameter is only valid in Europe.
68054E
Minimum pause between dialed digits
(pulse dial mode)
20 ms
See Note 3 and 8. SP2-103-016
(parameter 15).
68054F
Time waited when a pause is entered at
the operation panel
SP2-103-017 (parameter 16). See Note 3.
680550
DTMF tone on time
1 ms
SP2-103-018 (parameter 17).
680551
DTMF tone off time
SP2-103-019 (parameter 18).
680552
Tone attenuation level of DTMF signals
while dialing
-N x 0.5
–3.5 dBm
SP2-103-020 (parameter 19).
See Note 5.
680553
Tone attenuation value difference
between high frequency tone and low
frequency tone in DTMF signals
-dBm x 0.5
SP2-103-021 (parameter 20).
The setting must be less than –5dBm, and
should not exceed the setting at 680552h
above.
See Note 5.
680554
PSTN: DTMF tone attenuation level after
dialing
-N x 0.5
–3.5 dBm
SP2-103-022 (parameter 21). See Note 5.
680555
ISDN: DTMF tone attenuation level after
dialing
-dBm x 0.5
See Note 5.
680556
Not used
-
Do not change the settings.
680557
Time between 68054Dh (NCU
parameter 14) and 68054Eh (NCU
parameter 15)
1 ms
This parameter takes effect when the country
code is set to France.
680558
Not used
-
Do not change the setting.
680559
Grounding time (ground start mode)
20 ms
The Gs relay is closed for this interval.
68055A
Break time (flash start mode)
1 ms
The OHDI relay is open for this interval.
68055B
International dial access code (High)
BCD
For a code of 100:
68055B - F1
68055C - 00
68055C
International dial access code (Low)
68055D
PSTN access pause time
20 ms
This time is waited for each pause input after
the PSTN access code. If this address
contains FF[H], the pause time stored in
address 68054F is used.
Do not set a number more than 7 in the UK.
68055E
Progress tone detection level, and
cadence detection enable flags
Bit 7: 0, Bit 6: 0, Bit 5: 0 = -25.0 dBm
Bit 7: 0, Bit 6: 0, Bit 5: 1 = -35.0 dBm
