Ricoh M0A0

2.Installation
69
13. Pass the USB cable through the hole.
14. Attach the SPDF bottom cover [A] with the NFC card reader to the SPDF.
15. Pass the USB cable [B] through the clamp [A].
16. Remove the tab [A] and the short tab [B] from the rear of the SPDF rear cover [C].
