Operation
Road traffic
6.10.2 Additional axles
The additional axles must be activated when driving on the road. The highest speed
can be reached only when the additional axles are activated.
The additional axles are activated with the key (10) on keypad I. The LED lights up
when the additional axles are lowered. The symbol appears on the R-Touch main
terminal.
The axles may not be used for driving off roads, and therefore must be lifted up for dri-
ving off roads. If you switch from operating mode "Rabbit" to operating mode "Turtle"
while the additional axles are lowered, the R-Touch displays the following warning icon
. The additional axles can be raised by pressing the key (10). The LED goes out
once the additional axles are raised. The symbol appears on the R-Touch main ter-
minal.
201 / 546
